ab CHF 10.90

💬 076 222 45 99 (WhatsApp / SMS)

Welcome to our store.   We are Shenzhen Hi-Link Electronic co.,ltd, manufacturer of Sensor module,Router Module,WIFI module, BT module , AC DC and DC DC power module for ten years in China. If you need samples, please place order here, we will ship to you soon. If you need more quantity, welcome to contact us directly, we will provide you best price and best shipping method to you. Choose us with high quality and favourable prices.  HLK-LD2450 1. Product introduction Motion target tracking is to track the position of the moving target in the region in real time, and realize the distance, angle and speed measurement of the moving target in the region.The LD2450 is a motion target tracking sensor module from the Hilink 24G millimetre wave radar series, which includes extremely simplified 24 GHz radar sensor hardware and intelligent algorithm firmware. The solution is mainly used in general indoor scenarios such as homes, offices and hotels to enable the location tracking of moving human bodies.   The sensor hardware consists of an AloT millimetre wave radar chip, a high performance one-transmitter-two-receiver microstrip antenna and a low cost MCU and peripheral auxiliary circuitry. The intelligent algorithm firmware uses FMCW waveforms and the radar chip's proprietary advanced signal processing technology. It supports serial output of detection data, which is plug-and-play and can be flexibly applied to different smart scenarios and end products. 2. Product Features 24 GHz ISM band Integrated intelligent millimeter wave radar chip and intelligent algorithm firmware Precise motion target localization and tracking Longest detection range 6m Ultra-small module size: 15mm x 44mm Wall mounting Azimuth angle ±60°, pitch angle ±35° The ultimate cost-effective choice Multiple connection options with pin and socket interface 3. Solution advantages LD2450 human body sensing m
